Zoom H8 8-Input / 12-Track Portable Handy Recorder


In stock


Share this product


Product details

  • Three app-driven modes for podcasting, music, and field recording
  • Large, crisp touchscreen LED display
  • Integrated effects and multi-channel audio interface
  • 24-bit/96kHz highly immersive audio fidelity with XYH-6 capsule
  • Complete with Cubase LE and WaveLab Cast apps

Three interfaces in one – podcasting, music, and field recording
The Zoom H8 is one of the most advanced and cutting-edge recorders on the market. The thing that sets the H8 recorder apart from conventional recorders is the quick and easy workflow. The touchscreen display features three main recording modes that cater to different applications. The modes are comprised of: Music, Podcast, and Field. Each mode optimizes the H8 to capture the best possible recording, no matter the situation.

The three app-driven modes adapt to your recording scenario at the touch of a button. For example, the “Podcast” mode provides you with a versatile app that incorporates a range of exclusive features. It provides you with dedicated sound pads which you can use to Sound FX, jingles, music bites, and more.

Using the “Music” app mode, the H8 will provide you with a wide range of useful parameters and settings. It allows you to adjust audio levels, provides real-time metering, and much more, allowing you to have optimal control over your inputs and outputs. Record, mix and edit with ease.

Completing the trifecta is the “Field” app mode which optimizes the recorder for field recording. It provides you with all the key features you could need when recording on location. Large meters are displayed for keeping an eye on your levels as well as allowing you to adjust the low-cut filter, compression, limiter, and much more.

Immersive sound with interchangeable capsules
At the heart of the H8 is the XYH-6 microphone capsule. This stereo X/Y capsule is perfect for a wide range of recording applications. From recording immersive field sounds and vocal ensembles to capturing studio-grade sound for podcasts and more, the H8 can do it all. The included unidirectional capsule delivers stunning signal clarity and audio fidelity, capturing every nuance of your audio source.

You can swap between a wide array of microphone types thanks to the interchangeable capsule system. For example, should you require more immersive 360-degree audio you could swap in the VRH-8 capsule found on the ambisonic microphone. This capsule would be perfect for recording live performances, podcasts, and even sound for film. There are six interchangeable capsules (not included) to choose from, so you can always capture the sound you want.

Onboard effects and multi-channel audio interface
As well as the optimized workflow, the H8 boasts a range of onboard effects that you can use to optimize your recordings before the processing and editing stage. For example, you could use the built-in compression to ensure a solid signal level throughout, ideal for podcasting and other applications. The built-in low-cut filter is also great for minimizing unwanted rumble when field recording or capturing sound in a busy environment.

Boasting a wide range of inputs and outputs, the H8 can also be used as a premium-grade, multi-channel audio interface. Using the USB connection, you can connect the Zoom H8 to your PC, Mac, iPad or tablet device. From there, you can utilize up to 12 channels of simultaneous recording. Connections are comprised of four XLR inputs (with pad switches and gain controls) as well as two XLR/TRS combo jacks with Hi-Z switches. You can also monitor your tracks using the headphone output or mount it directly to your camera using the dedicated stereo line input.

Easy navigation with touchscreen LCD display
The large and clear LCD display features a touchscreen design that allows you to get hands-on with your settings and parameters. This bright touchscreen allows you to navigate your different modes and parameters with ease, providing an ergonomic layout that is quick and easy to use. You can even use the BTA-1 (not included) to use your iOS device as a remote control, for even more portability.

State-of-the-art editing
The H8 comes complete with the powerful Cubase LE and WaveLab Cast software. These two applications allow you to edit, mix and finalize your product with a wide range of complex and versatile refinement tools. Cubase LE is a powerful app-based version of the award-winning Cubase DAW. You can record, edit, mix and even master your audio within this versatile digital audio workstation.

WaveLab Cast is the perfect companion for podcasters. It allows you to connect directly to podcast providers such as Spreaker or Podbean. This allows you to upload episodes quicker than ever, as well as providing the means to create and publish RSS feeds. Importing a video file within WaveLab will allow you to extract the audio and using the built-in editing tools to optimize the sound. WaveLab Cast also provides support for up to 96kHz audio resolutions as well as boasting a premium-grade re-sampler for polishing off your audio tracks.

One of the most advanced handheld recorders on the market
Customized controls for podcasting, field recording, and music
Record up to 12 tracks simultaneously
Interchangeable microphone input capsules
Records directly to SD, SDHC, and SDXC cards up to 512GB
Up to 24-bit /96kHz audio in BWF-compliant WAV or a variety of MP3 formats
Onboard effects for optimizing audio recording including reverb, compression and delay
Navigate settings easily with a large LCD touchscreen display
Complete with XYH-6 X/Y capsule which provides secondary input via a stereo 1/4-inch Mic/Line In mini phone jack
Up to 20 hours of battery life from AA alkaline batteries (battery life is approximate depending on usage)
Number of input channels: 8 (XY mic capsule, 1-4, A, B)
Number of output channels: 2 (stereo headphone and stereo line)
MIC IN: ZOOM mic connector
INPUT 1-4: XLR jacks (2: HOT)
INPUT A/B: XLR/TRS combo jacks (XLR: 2 hot, TRS: TIP hot)
USB: USB Micro-B (audio interface, mass storage, and Guitar Lab connection functions) (Note: Use a USB cable that supports data transfer. Operation using USB bus power is possible)
REMOTE: ZOOM BTA-1 or other dedicated wireless adapters
LINE OUT: 3.5 mm stereo mini
PHONE OUT: 3.5 mm stereo mini
Phantom power: +24 V/+48 V (independent ON/OFF for INPUTS 1–4, A and B)
Recording media: Cards that support SD/SDHC/SDXC specifications
WAV: 44.1/48/96 kHz, 16/24-bit, mono/stereo
MP3: 128, 192, 320 kbps
Maximum simultaneous recording tracks: 12 (MIC IN, backup recording, 1-4, A, B, and LR)
Audio interface:
Multitrack mode: 44.1/48/96 kHz, 16/24-bit, 12-in/2-out
Stereo mix mode: 44.1/48 kHz, 24-bit, 2-in/2-out
Tuner: Chromatic/Guitar/Bass/Open A/Open D/Open E/Open G/DADGAD
Built-in speaker: 400 mW 8 ohms mono speaker
Display: 2.4″ (320×240) full-colour touchscreen LCD
4 AA batteries (alkaline, NiMH or lithium)
AC adapter (ZOOM AD-17): DC 5 V/1A
USB bus power
Estimated continuous operation time using batteries (hours: minutes): Using alkaline batteries, Using XY mic, 44.1 kHz/24-bit (stereo × 1): about 15:00 (values are approximate)
H8 External dimensions: 116.4 mm (W) × 163.3 mm (D) × 48.6 mm (H)
XYH-6 Dimensions: 78.9 mm (W) × 60.2 mm (D) × 45.2 mm (H)
H8 Weight: 354 g
XYH-6 Weight: 130 g
